GI
The abdomen can look quiet while the bowel is losing blood flow.
Perfusion territories
The figure links arterial supply to vulnerable tissue and the expected ischemic findings.
Quick check
A 76-year-old with atrial fibrillation develops abrupt severe periumbilical pain. The abdomen is soft with minimal tenderness.
Reason it through
Vessel, bowel wall, and peritoneum tell one story.
An arterial filling defect or ostial cutoff identifies inflow failure; a mesenteric venous filling defect with edema suggests outflow obstruction.
Reduced mural enhancement, pneumatosis, portal venous gas, free fluid, or free air increase concern for advanced injury.
NOMI may show patent major vessels with diffuse narrowing and poorly enhancing bowel in a low-flow patient.
Point to the clue that changes management.
Ostial plaque and thrombosis favor acute-on-chronic arterial disease
A discrete embolus commonly lodges beyond proximal branches
Thrombus plus edematous bowel supports venous ischemia
Absent enhancement and pneumatosis raise concern for necrosis
Free air or peritonitis demands operative control
Resuscitation and diagnosis move together.
Obtain CTA promptly even with kidney injury when AMI is strongly suspected because diagnostic delay is more dangerous.
Start fluids, correct electrolytes and acidosis, provide broad-spectrum antibiotics, and involve vascular and surgical teams.
Restore arterial inflow when occluded, anticoagulate venous thrombosis, and resect only irreversibly necrotic bowel.
Order the actions from suspicion to definitive control.
Move from suspicion to infarction on a clinical scale.
A soft abdomen with severe pain is early danger, not low risk.
Guarding, shock, absent enhancement, pneumatosis, portal venous gas, and free air progressively increase the probability of transmural necrosis.
Do not wait for a particular lactate value before calling vascular surgery or the operating room.
Place the findings from early threat to irreversible injury.
Name the vessel problem before choosing the rescue.
An SMA embolus often produces abrupt pain in a patient with atrial fibrillation and may lodge beyond the artery origin.
In-situ thrombosis commonly overlays ostial atherosclerosis and may follow chronic postprandial symptoms.
NOMI is severe vasoconstriction during shock or high-dose vasopressors; mesenteric venous thrombosis blocks outflow and causes bowel-wall edema.
Match each mechanism to its clinical fingerprint.
Abrupt onset, cardiac source, relatively spared SMA origin
Atherosclerotic ostial disease, sometimes prior intestinal angina
Low-flow state or vasopressors without a large-vessel plug
Hypercoagulability, portal inflammation, or thrombophilia with venous filling defect
A number cannot clear a threatened mesentery.
Lactate may remain normal early and can rise from many shock states.
Leukocytosis, acidosis, and D-dimer may support concern but none safely rules AMI in or out.
Peritonitis signals transmural injury and changes the plan from imaging-only management to urgent operative assessment.
Select the statement that should drive bedside behavior.
Choose the first item.
There is no single AMI drug list.
Arterial occlusion needs urgent revascularization when salvageable bowel remains; endovascular-first strategies are favored when expertise and anatomy permit.
Mesenteric venous thrombosis without peritonitis is generally treated with immediate full-dose anticoagulation and close observation.
NOMI management reverses the low-flow trigger, reduces vasoconstrictors when possible, and may use catheter-directed vasodilator therapy; necrotic bowel still requires surgery.
Reveal the cause-directed move.
Stage 1 of 3: Overview
Overview
Resuscitation and diagnosis move together.
Flow check
Choose the perfusion clue that localizes the injured tissue.
Which diagnostic study should be obtained next?
Six hours in the emergency department can separate reversible ischemia from short bowel syndrome.
Cross out the wrong vascular territory and highlight the threatened tissue. Each case links vessel, bed, and consequence.
A 79-year-old with atrial fibrillation has sudden severe abdominal pain and an SMA filling defect distal to the origin.
Reason it through
A smoker with months of postprandial pain now has continuous pain. CTA shows calcified ostial SMA plaque with superimposed occlusion.
Reason it through
A patient in septic shock on escalating norepinephrine develops distention and rising abdominal pain. CTA shows patent proximal mesenteric arteries with diffuse branch narrowing.
Reason it through
A postpartum patient with inherited thrombophilia has diffuse abdominal pain. CTA shows superior mesenteric vein thrombosis and bowel-wall edema without peritonitis.
Reason it through
A patient with suspected AMI develops rebound tenderness, shock, free intraperitoneal air, and nonenhancing small bowel.
Reason it through
Rapid review
Immediate CT angiography of the abdomen and pelvis. Abrupt pain out of proportion plus an embolic source demands CTA without delay.
Abrupt.
Distal SMA.
